Proximity Switch Torque Tester with Mitsubishi PLC Control

Guangzhou HongCe Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Proximity Switch Torque Tester with Mitsubishi PLC Control

  • 1
  • 2
  • 3

Brand Name : HongCe

Model Number : HO6508

Certification : Calibration certificate(cost additional)

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T

Supply Ability : 10 sets per month

Delivery Time : 30 days

Packaging Details : Plywood

Control system : Mitsubishi PLC intelligent electrical control + man-machine integrated interface operation

Drive mode : Servo motor

Station : Single

Torque test : 0.1Nm (360°)

Push test : 20N

Bend test : ±90°rotation, 3kg mass loaded

Contact Now

High-Precision Proximity Switch Torque Tester - Professional Plug Socket Tester Multi-Function Testing Instrument

Product Introduction For Plug Socket Tester:

This tester is made specifically to check how strong proximity switches with attached cables are. It follows the IEC 60947-5-2: 2007 Annex C.8 standard. It's build to see if different proximity switches and photoelectric sensors with built-in cables can handle stress, making sure the cables stay firmly connected to the switch.

The machine uses a smart PLC control system and an easy-to-use touch screen, so recording and showing results is more precise. You can set how many times it tests something, how fast it tests, how far it moves during the test, and how much force it uses. After the test, the recorded data helps you to determine if the item passed or failed.

Technical Parameters For Plug Socket Tester:

Model HO6508
Input power AC220V 50Hz
Control system Mitsubishi PLC intelligent electrical control + man-machine integrated interface operation
Drive mode Servo motor
Station Single
Test item Pull test: pull force 160N (d≥8mm) or 20d (d<8mm)
Torque test: 0.1Nm (360°)
Push test: 20N
Bend test: ±90°rotation, 3kg mass loaded
Test time 0-999.9s, can preset each test item’s test time
Test number 0-9999times, can preset each test item’s test number
Load mass 3kg
Test sample

Proximity switch, photoelectric sensor and other similar products with integral connecting cable, the sample switch part is not more than 50*50*50mm, and the cable diameter is not more than 16mm

Testing Items For Plug Socket Tester:
Plotting switch plug-in/plug-out life curves
Detecting critical fatigue points of return springs
Contact pressure decay analysis
Torque retention in extreme environments
Millimeter-level panel deformation monitoring
Stroke force consistency

Picture for reference For Plug Socket Tester:
Proximity Switch Torque Tester with Mitsubishi PLC Control

Quality After-Sales Service For Plug Socket Tester:

Equipment Warranty: From the date of equipment acceptance, we provide a 12-month free warranty. During this period, we will repair or replace parts for any equipment failures caused by quality issues.

Technical Support: Our professional technical team provides 24/7 technical consulting services to answer any questions you may have about the equipment.

Regular Maintenance: During the warranty period, we will perform regular maintenance on the equipment to ensure it remains in good working order.

Training: We provide free training to help your operators master the operation and routine maintenance of the equipment.

Spare Parts Supply: We provide a long-term supply of high-quality parts to ensure timely delivery of parts for equipment repairs.
